656User Manual 1335.9090.02 ─ 09
●
TRIGger:A:SOURce to SBUS1 | SBUS2
TRIGger:A:LIN:TYPE..................................................................................................... 656
TRIGger:A:LIN:CHKSerror.............................................................................................. 656
TRIGger:A:LIN:IPERror.................................................................................................. 657
TRIGger:A:LIN:SYERror................................................................................................. 657
TRIGger:A:LIN:ICONdition.............................................................................................. 657
TRIGger:A:LIN:IDENtifier................................................................................................ 657
TRIGger:A:LIN:DATA......................................................................................................657
TRIGger:A:LIN:DCONdition.............................................................................................658
TRIGger:A:LIN:DLENgth.................................................................................................658
TRIGger:A:LIN:TYPE <TriggerType>
Specifies the trigger mode for LIN.
Parameters:
<TriggerType> SYNC | WKFRame | ID | IDDT | ERRCondition
SYNC
Start of frame, triggers on the stop bit of the sync field.
WKFRame
Triggers after a wakeup frame.
ID
Sets the trigger to a specific identifier or an identifier range.
Set the identifier with TRIGger:A:LIN:ICONdition and
TRIGger:A:LIN:IDENtifier.
IDDT
Set the identifier (see ID) and the data with TRIGger:A:LIN:
DLENgth, TRIGger:A:LIN:DCONdition and TRIGger:A:
LIN:DATA.
ERRCondition
Identifies various errors in the frame. You can select one or
more error types as trigger condition.
Select the error types with TRIGger:A:LIN:CHKSerror,
TRIGger:A:LIN:IPERror and TRIGger:A:LIN:SYERror.
*RST:
SYNC
TRIGger:A:LIN:CHKSerror <ChecksumError>
Triggers on a checksum error. The checksum verifies the correct data transmission. It
is the last byte of the frame response. The checksum includes not only the data but
also the protected identifier (PID).
The command is relevant if TRIGger:A:LIN:TYPE is set to ERRCondition.
Parameters:
<ChecksumError> ON | OFF
*RST: ON
