Rohde & Schwarz RTM3K-COM2 User Manual

Remote control commands
R&S
®
RTM3000
657User Manual 1335.9090.02 ─ 09
TRIGger:A:LIN:IPERror <IdParityError>
Triggers on a parity error. Parity bits are the bits 6 and 7 of the identifier. They verify
the correct transmission of the identifier.
The command is relevant if TRIGger:A:LIN:TYPE is set to ERRCondition.
Parameters:
<IdParityError> ON | OFF
*RST: OFF
TRIGger:A:LIN:SYERror <SyncError>
Triggers if synchronization caused an error.
The command is relevant if TRIGger:A:LIN:TYPE is set to ERRCondition.
Parameters:
<SyncError> ON | OFF
*RST: OFF
TRIGger:A:LIN:ICONdition <IdentifierCondition>
Sets the comparison condition for the identifier: If the pattern contains at least one X
(don't care), you can trigger on values equal or not equal to the specified value. If the
pattern contains only 0 and 1, you can also trigger on a range greater than or lower
than the specified value.
The command is relevant if TRIGger:A:LIN:TYPE is set to ID or IDDT.
Parameters:
<IdentifierCondition> EQUal | NEQual | GTHan | LTHan
*RST: EQ
TRIGger:A:LIN:IDENtifier <Identifier>
Defines the identifier pattern.
The command is relevant if TRIGger:A:LIN:TYPE is set to ID or IDDT.
Parameters:
<Identifier> String containing binary pattern. Characters 0, 1, and X are
allowed. Enter the 6 bit identifier without parity bits, not the pro-
tected identifier.
TRIGger:A:LIN:DATA <Data>
Defines the data pattern. The number of bytes in the data pattern is defined with
TRIGger:A:LIN:DLENgth.
The command is relevant if TRIGger:A:LIN:TYPE is set to IDDT.
Serial bus analysis
