Remote control commands
R&S
®
RTM3000
658User Manual 1335.9090.02 ─ 09
Parameters:
<Data> String containing binary pattern with max. 64 bit. Characters 0,
1, and X are allowed. Make sure to enter complete bytes.
TRIGger:A:LIN:DCONdition <DataCondition>
Sets the comparison condition for data: If the pattern contains at least one X (don't
care), you can trigger on values equal or not equal to the specified value. If the pattern
contains only 0 and 1, you can also trigger on a range greater than or lower than the
specified value.
The command is relevant if TRIGger:A:LIN:TYPE is set to IDDT.
Parameters:
<DataCondition> EQUal | NEQual | GTHan | LTHan
*RST: EQ
TRIGger:A:LIN:DLENgth
<DataLength>
Defines the length of the data pattern - the number of bytes in the pattern.
The command is relevant if TRIGger:A:LIN:TYPE is set to IDDT.
Parameters:
<DataLength> Range: 1 to 8
Increment: 1
*RST: 1
Default unit: Byte
17.11.6.3 LIN - decode results
In all BUS<b>:LIN... commands, the suffix <b> selects the bus.
BUS<b>:LIN:FCOunt?....................................................................................................659
BUS<b>:LIN:FRAMe<n>:DATA?......................................................................................659
BUS<b>:LIN:FRAMe<n>:STATus?...................................................................................659
BUS<b>:LIN:FRAMe<n>:STARt?.....................................................................................659
BUS<b>:LIN:FRAMe<n>:STOP?..................................................................................... 660
BUS<b>:LIN:FRAMe<n>:CSSTate?................................................................................. 660
BUS<b>:LIN:FRAMe<n>:CSValue?................................................................................. 660
BUS<b>:LIN:FRAMe<n>:IDPValue?................................................................................ 661
BUS<b>:LIN:FRAMe<n>:IDSTate?.................................................................................. 661
BUS<b>:LIN:FRAMe<n>:IDValue?...................................................................................661
BUS<b>:LIN:FRAMe<n>:SYSTate?................................................................................. 662
BUS<b>:LIN:FRAMe<n>:SYValue?..................................................................................662
BUS<b>:LIN:FRAMe<n>:VERSion?.................................................................................662
BUS<b>:LIN:FRAMe<n>:BCOunt?.................................................................................. 662
BUS<b>:LIN:FRAMe<n>:BYTE<o>:STATe?......................................................................663
BUS<b>:LIN:FRAMe<n>:BYTE<o>:VALue?..................................................................... 663
Serial bus analysis
