Remote control commands
R&S
®
RTM3000
653User Manual 1335.9090.02 ─ 09
Parameters:
<IdType> B11 | B29
*RST: B11
SEARch:PROTocol:CAN:ICONdition <IdCondition>
Sets the comparison condition for the identifier: If the pattern contains at least one X
(don't care), you can trigger on values equal or not equal to the specified value. If the
pattern contains only 0 and 1, you can also trigger on a range greater than or lower
than the specified value.
The command is relevant if SEARch:PROTocol:CAN:CONDition is set to
IDENtifier, IDData, or IDERror.
Parameters:
<IdCondition> EQUal | NEQual | GTHan | LTHan
*RST: EQU
SEARch:PROTocol:CAN:IDENtifier
<Identifier>
Defines the identifier pattern. The pattern length is defined with SEARch:PROTocol:
CAN:ITYPe.
The command is relevant if SEARch:PROTocol:CAN:CONDition is set to
IDENtifier, IDData, or IDERror.
Parameters:
<Identifier> String containing binary pattern with max. 29 bit. Characters 0,
1, and X are allowed.
SEARch:PROTocol:CAN:DLENgth <DataLength>
Defines the length of the data pattern - the number of bytes in the pattern.
The command is relevant if SEARch:PROTocol:CAN:CONDition is set to IDData.
Parameters:
<DataLength> Range: 0 to 8
Increment: 1
*RST: 1
Default unit: Byte
SEARch:PROTocol:CAN:DCONdition <DataCondition>
Sets the comparison condition for data: If the pattern contains at least one X (don't
care), you can trigger on values equal or not equal to the specified value. If the pattern
contains only 0 and 1, you can also trigger on a range greater than or lower than the
specified value.
The command is relevant if SEARch:PROTocol:CAN:CONDition is set to IDData.
Serial bus analysis
