17.11.6.4 LIN - search
SEARch:PROTocol:LIN:CONDition.................................................................................. 664
SEARch:PROTocol:LIN:FRAMe.......................................................................................664
SEARch:PROTocol:LIN:IPERror...................................................................................... 665
SEARch:PROTocol:LIN:CHKSerror..................................................................................665
SEARch:PROTocol:LIN:SYERror.....................................................................................665
SEARch:PROTocol:LIN:ICONdition..................................................................................665
SEARch:PROTocol:LIN:IDENtifier....................................................................................666
SEARch:PROTocol:LIN:DLENgth.....................................................................................666
SEARch:PROTocol:LIN:DCONdition................................................................................ 666
SEARch:PROTocol:LIN:DATA..........................................................................................666
SEARch:PROTocol:LIN:CONDition <SearchCondition>
Sets the event or combination of events to be searched for. Depending on the selected
event, further settings are required.
Parameters:
<SearchCondition> FRAMe | ERRor | IDENtifier | IDData | IDERror
FRAMe
Search for a frame type.
Set the frame type with SEARch:PROTocol:LIN:FRAMe.
ERRor
Search for errors of one or more error types.
Set the error types withSEARch:PROTocol:LIN:CHKSerror ,
SEARch:PROTocol:LIN:IPERror and SEARch:PROTocol:
LIN:SYERror.
IDENtifier
Search for identifier.
Specifiy the identifier with SEARch:PROTocol:LIN:
ICONdition and SEARch:PROTocol:LIN:IDENtifier.
IDData
Search for identifier and data.
Set the identifier (see IDENtifier) and the data with SEARch:
PROTocol:LIN:DLENgth, SEARch:PROTocol:LIN:
DCONdition and SEARch:PROTocol:LIN:DATA.
IDERror
Search for errors that occur with a specified identifier. Set the
identifier (see IDENtifier) and the errors to be found (see
ERRor).
*RST:
FRAM
SEARch:PROTocol:LIN:FRAMe <Frame>
Selects the frame type to be searched for.
The command is relevant if SEARch:PROTocol:LIN:CONDition is set to FRAMe.
