Remote control commands
R&S
®
RTM3000
783User Manual 1335.9090.02 ─ 09
WGENerator:ARBitrary:VISible <ArbWaveformVisible>
Enables the display of the arbitrary waveform.
Parameters:
<ArbWaveformVisible>ON | OFF
*RST: OFF
17.14.1.3 Burst settings
WGENerator:BURSt:ITIMe..............................................................................................783
WGENerator:BURSt:NCYCle.......................................................................................... 783
WGENerator:BURSt:PHASe........................................................................................... 783
WGENerator:BURSt[:STATe]...........................................................................................783
WGENerator:BURSt:ITIMe <IdleTime>
Sets the idle time between two burst cycles.
Parameters:
<IdleTime> Range: 28n to 17
*RST: 100u
Default unit: s
WGENerator:BURSt:NCYCle <NumberOfCycles>
Sets the number of times the generator outputs one cycle of the waveform per burst.
Parameters:
<NumberOfCycles> Range: 1 to 1023
Increment: 1
*RST: 1
WGENerator:BURSt:PHASe <PhaseOffset>
Sets the start phase of the burst.
Parameters:
<PhaseOffset> Range: 0 to 360
Increment: 0.1
*RST: 0
Default unit: Degree
WGENerator:BURSt[:STATe] <Enable>
Enables or disables the burst. for the generator.
Parameters:
<Enable> ON | OFF
*RST: OFF
Signal generation (option R&S RTM-B6)
