Remote control commands
R&S
®
RTM3000
782User Manual 1335.9090.02 ─ 09
WGENerator:ARBitrary[:FILE]:NAME............................................................................... 782
WGENerator:ARBitrary[:FILE]:OPEN............................................................................... 782
WGENerator:ARBitrary:VISible........................................................................................783
WGENerator:ARBitrary:SOURce <Source>
Selects the input channel for an arbitrary function to be generated.
Parameters:
<Source> CH1 | CH2 | CH3 | CH4
*RST: CH1
WGENerator:ARBitrary:RANGe:START <StartTime>
Sets the start time of the copied waveform part.
Parameters:
<StartTime> Default unit: s
WGENerator:ARBitrary:RANGe:STOP <StopTime>
Sets the end time of the copied waveform part.
Parameters:
<StopTime> Default unit: s
WGENerator:ARBitrary:UPDate
Loads the waveform from the selected signal source (WGENerator:ARBitrary:
SOURce).
Usage:
Event
WGENerator:ARBitrary[:FILE]:NAME <FilePath>
Sets the file path and the file for an arbitrary waveform to be loaded.
Parameters:
<FilePath> string
*RST: "
WGENerator:ARBitrary[:FILE]:OPEN
Loads the arbitrary waveform, that is selected with the WGENerator:ARBitrary[:
FILE]:NAME command.
Usage:
Event
Signal generation (option R&S RTM-B6)
