Remote control commands
R&S
®
RTM3000
781User Manual 1335.9090.02 ─ 09
WGENerator:FUNCtion:EXPonential:POLarity <Polarity>
Sets the polarity of the generator function exponential.
Parameters:
<Polarity> POSitive | NEGative
WGENerator:FUNCtion:RAMP:POLarity <Polarity>
Sets the polarity of the generator function ramp.
Parameters:
<Polarity> POSitive | NEGative
*RST: NEG
WGENerator:NOISe:ABSolute <AbsoluteNoise>
Sets the noise of the waveform in volts.
Parameters:
<AbsoluteNoise>
WGENerator:NOISe:RELative <RelativeNoise>
Sets the noise of the generated waveform in percentage of the amplitude.
Parameters:
<RelativeNoise>
WGENerator:OUTPut:LOAD <Load>
Select the user load, the load of the DUT at its connection. You can select either a
"50Ω" or a "High-Z" (high input impedance) load.
Parameters:
<Load> HIGHz | R50
WGENerator:OUTPut[:ENABle] <OutputEnable>
Enables the function generator and outputs the waveform.
Parameters:
<OutputEnable> ON | OFF
17.14.1.2 Arbitrary waveform setup
WGENerator:ARBitrary:SOURce..................................................................................... 782
WGENerator:ARBitrary:RANGe:START............................................................................782
WGENerator:ARBitrary:RANGe:STOP............................................................................. 782
WGENerator:ARBitrary:UPDate.......................................................................................782
Signal generation (option R&S
RTM-B6)
