Remote control commands

R&S

RTM3000

784User Manual 1335.9090.02 ─ 09

17.14.1.4 Modulation settings

WGENerator:MODulation[:ENABLE]................................................................................ 784

WGENerator:MODulation:FUNCtion.................................................................................784

WGENerator:MODulation:TYPE...................................................................................... 784

WGENerator:MODulation:AM:FREQuency....................................................................... 785

WGENerator:MODulation:AM:DEPTh...............................................................................785

WGENerator:MODulation:FM:FREQuency........................................................................785

WGENerator:MODulation:FM:DEViation...........................................................................785

WGENerator:MODulation:ASK:FREQuency......................................................................785

WGENerator:MODulation:ASK:DEPTh.............................................................................785

WGENerator:MODulation:FSK:HFREquency.................................................................... 786

WGENerator:MODulation:FSK:RATE............................................................................... 786

WGENerator:MODulation:RAMP:POLarity........................................................................786

WGENerator:MODulation[:ENABLE] <Enable>

Activates or deactivates modulation of the function generator output. To define the

modulation function, see WGENerator:MODulation:FUNCtion.

Parameters:

<Enable> ON | OFF

WGENerator:MODulation:FUNCtion <ModulationFunction>

Selects a function for the modulation.

Parameters:

<ModulationFunction>SINusiod | SQUare | TRIangle | RAMP

WGENerator:MODulation:TYPE <ModulationType>

Sets the modulation type, which defines how the carrier signal is modified.

Parameters:

<ModulationType> AM | FM | ASK | FSK

Amplitude modulation. The amplitude of the carrier signal is var-

ied according to the modulation signal.

Frequency modulation. The frequency of the carrier signal is var-

ied according to the modulation signal.

ASK

Amplitude shift keying (ASK) modulation. The amplitude

switches between 100% and the WGENerator:MODulation:

ASK:DEPTh amplitude with a defined modulating WGENerator:

MODulation:ASK:FREQuency.

Signal generation (option R&S RTM-B6)
