Remote control commands
R&S
®
RTM3000
494User Manual 1335.9090.02 ─ 09
17.6.4.6 Runt search configuration
SEARch:TRIGger:RUNT:POLarity....................................................................................494
SEARch:TRIGger:LEVel:RUNT:LOWer.............................................................................494
SEARch:TRIGger:LEVel:RUNT:UPPer............................................................................. 494
SEARch:TRIGger:RUNT:RANGe..................................................................................... 494
SEARch:TRIGger:RUNT:WIDTh...................................................................................... 495
SEARch:TRIGger:RUNT:DELTa.......................................................................................495
SEARch:TRIGger:RUNT:POLarity <Polarity>
Indicates the polarity of a the runt to be searched for.
Parameters:
<Polarity> POSitive | NEGative | EITHer
*RST: POS
SEARch:TRIGger:LEVel:RUNT:LOWer <LowerLevel>
Sets the lower voltage threshold for runt detection. A positive runt crosses the lower
level twice without crossing the upper level.
Parameters:
<LowerLevel> Range: Depends on vertical scale and LSB value.
*RST: 400 mV
Default unit: V
SEARch:TRIGger:LEVel:RUNT:UPPer <UpperLevel>
Sets the upper voltage threshold for runt detection. A negative runt crosses the upper
level twice without crossing the lower level.
Parameters:
<UpperLevel> Range: Depends on vertical scale and LSB value.
*RST: 600 mV
Default unit: V
SEARch:TRIGger:RUNT:RANGe <Range>
Sets how the measured pulse width is compared with the given limit(s).
To set the width, use SEARch:TRIGger:RUNT:WIDTh.
To set the range ± Δt, use SEARch:TRIGger:RUNT:DELTa.
Parameters:
<Range> LONGer | SHORter | WITHin | OUTSide
LONGer
Finds pulses longer than the given width.
SHORter
Finds pulses shorter than the given width.
Waveform analysis
