Remote control commands
R&S
®
RTM3000
493User Manual 1335.9090.02 ─ 09
SEARch:TRIGger:LEVel:RISetime:UPPer <UpperLevel>
Sets the upper voltage threshold. When the signal crosses this level, the rise/fall time
measurement starts or stops depending on the selected slope.
Parameters:
<UpperLevel> *RST: 600 mV
Default unit: V
SEARch:TRIGger:RISetime:RANGe <Range>
Sets how the measured rise or fall time is compared with the given limit(s).
To set the rise/fall time, use SEARch:TRIGger:RISetime:TIME.
To set the range ± Δt, use SEARch:TRIGger:RISetime:DELTa.
Parameters:
<Range> LONGer | SHORter | WITHin | OUTSide
LONGer
Finds rise/fall times longer than the given time.
SHORter
Finds rise/fall times shorter than the given time.
WITHin
Finds rise/fall times inside the range time ± Δt.
OUTSide
Finds rise/fall times outside the range time ± Δt.
*RST: LONG
SEARch:TRIGger:RISetime:TIME <Time>
Sets the reference rise or fall time, the nominal value for comparisons.
Parameters:
<Time> Range: Depends on various settings, mainly time base and
sample rate
*RST: 200e-6
Default unit: s
SEARch:TRIGger:RISetime:DELTa <DeltaTime>
Sets a range Δt to the reference rise/fall time set with SEARch:TRIGger:RISetime:
TIME, if SEARch:TRIGger:RISetime:RANGe is set to Within or Outside. The
instrument finds rise/fall times inside or outside the range time ± Δt.
Parameters:
<DeltaTime> Range: Depends on various settings, mainly time base and
sample rate
*RST: 50e-6
Default unit: s
Waveform analysis
