Remote control commands
R&S
®
RTM3000
492User Manual 1335.9090.02 ─ 09
17.6.4.4 Peak search configuration
SEARch:MEASure:PEAK:POLarity.................................................................................. 492
SEARch:MEASure:LEVel:PEAK:MAGNitude.....................................................................492
SEARch:MEASure:PEAK:POLarity <Polarity>
Indicates the polarity of a the pulse to be searched for a peak.
Parameters:
<Polarity> POSitive | NEGative | EITHer
*RST: POS
SEARch:MEASure:LEVel:PEAK:MAGNitude <Magnitude>
Sets the peak-to-peak limit. If the signal exceeds this limit, a search event is listed.
Parameters:
<Magnitude> Default unit: V
17.6.4.5 Rise/fall time search configuration
SEARch:TRIGger:RISetime:SLOPe................................................................................. 492
SEARch:TRIGger:LEVel:RISetime:LOWer........................................................................492
SEARch:TRIGger:LEVel:RISetime:UPPer.........................................................................493
SEARch:TRIGger:RISetime:RANGe................................................................................ 493
SEARch:TRIGger:RISetime:TIME....................................................................................493
SEARch:TRIGger:RISetime:DELTa.................................................................................. 493
SEARch:TRIGger:RISetime:SLOPe <Polarity>
Sets the slope to be found.
Parameters:
<Polarity> POSitive | NEGative | EITHer
POSitive: to search for rise time.
NEGative: to search for fall time.
EITHer: to search for rise and fall time.
*RST: POS
SEARch:TRIGger:LEVel:RISetime:LOWer <LowerLevel>
Sets the lower voltage threshold. When the signal crosses this level, the rise time mea-
surement starts or stops depending on the selected slope.
Parameters:
<LowerLevel> *RST: 400 mV
Default unit: V
Waveform analysis
