WITHin
Finds pulses inside the range width ± Δt.
OUTSide
Finds pulses outside the range width ± Δt.
*RST: LONG
SEARch:TRIGger:RUNT:WIDTh <Width>
Sets the reference runt pulse width, the nominal value for comparisons.
Parameters:
<Width> Range: Depends on various settings, mainly time base and
sample rate.
*RST: 200e-6
Default unit: s
SEARch:TRIGger:RUNT:DELTa <DeltaWidth>
Sets a range Δt to the reference pulse width set with SEARch:TRIGger:RUNT:WIDTh
, if SEARch:TRIGger:RUNT:RANGe is set to WITHin or OUTSide.
Parameters:
<DeltaWidth> Range: Depends on various settings, mainly time base and
sample rate.
*RST: 50e-6
Default unit: s
17.6.4.7 Data2Clock search configuration
SEARch:TRIGger:DATatoclock:CSOurce..........................................................................495
SEARch:TRIGger:DATatoclock:CLEVel............................................................................ 496
SEARch:TRIGger:DATatoclock:DLEVel............................................................................ 496
SEARch:TRIGger:DATatoclock:CLEVel:DELTa..................................................................496
SEARch:TRIGger:DATatoclock:DLEVel:DELTa..................................................................496
SEARch:TRIGger:DATatoclock:CEDGe............................................................................496
SEARch:TRIGger:DATatoclock:HTIMe............................................................................. 496
SEARch:TRIGger:DATatoclock:STIMe..............................................................................496
SEARch:TRIGger:DATatoclock:CSOurce <ClockSource>
Selects the input channel of the clock signal.
Parameters:
<ClockSource> CH1 | CH2 | CH3 | CH4
*RST: CH1
Waveform analysis
