Rohde & Schwarz RTM3K-COM2

Remote control commands
R&S
®
RTM3000
490User Manual 1335.9090.02 ─ 09
SEARch:TRIGger:EDGE:LEVel <Level>
Sets the voltage level for the edge search.
Parameters:
<Level> *RST: 0.5 V
SEARch:TRIGger:EDGE:LEVel:DELTa <DeltaLevel>
Sets a hysteresis range above and below the search level to avoid unwanted search
results caused by noise oscillation around the level.
Parameters:
<DeltaLevel> Range: Lower limit depends on vertical scale and other set-
tings, no upper limit
*RST: 0.2 V
17.6.4.3
Width search configuration
SEARch:TRIGger:WIDTh:POLarity.................................................................................. 490
SEARch:TRIGger:WIDTh:LEVel...................................................................................... 490
SEARch:TRIGger:WIDTh:LEVel:DELTa............................................................................490
SEARch:TRIGger:WIDTh:RANGe....................................................................................491
SEARch:TRIGger:WIDTh:WIDTh.....................................................................................491
SEARch:TRIGger:WIDTh:DELTa..................................................................................... 491
SEARch:TRIGger:WIDTh:POLarity <Polarity>
Indicates the polarity of the pulse to be searched for.
Parameters:
<Polarity> POSitive | NEGative
*RST: POS
Example: Chapter 17.2.3.1, "Searching for a pulse of specified width",
on page 429
SEARch:TRIGger:WIDTh:LEVel <Level>
Sets the voltage level on which the pulse width is measured.
Parameters:
<Level> *RST: 500 mV
SEARch:TRIGger:WIDTh:LEVel:DELTa <DeltaLevel>
Sets a hysteresis range above and below the search level to avoid unwanted search
results caused by noise oscillation around the level.
Waveform analysis
