Remote control commands
R&S
®
RTM3000
498User Manual 1335.9090.02 ─ 09
NOR
"Not or" operator, none of the channels has the required state.
*RST: AND
SEARch:TRIGger:PATTern:LEVel<n> <ThresholdLevel>
Sets the threshold value for the specified source channel. You can set different levels
for the channels
Suffix:
<n>
.
1..4
Selects the input channel. The number of channels depends on
the instrument.
Parameters:
<ThresholdLevel> Range: Depends on vertical scale
SEARch:TRIGger:PATTern:LEVel<n>:DELTa
<LevelDelta>
Sets a hysteresis range to the threshold of the specified source channel to avoid
unwanted search results caused by noise oscillation around the level.
Suffix:
<n>
.
1..4
Selects the input channel. The number of channels depends on
the instrument.
Parameters:
<LevelDelta> Range: Lower limit depends on vertical scale and other set-
tings, no upper limit
SEARch:TRIGger:PATTern:WIDTh:RANGe <Range>
Sets the condition how the duration of a steady pattern is compared with the given ref-
erence time.
To set the reference value width, use SEARch:TRIGger:PATTern:WIDTh[:WIDTh].
To set a range Δt, use SEARch:TRIGger:PATTern:WIDTh:DELTa
Parameters:
<Range> WITHin | OUTSide | LONGer | SHORter
WITHin
Finds patterns steady for a time range width ± Δt.
OUTSide
Finds patterns outside a time range width ± Δt.
LONGer
Finds patterns steady for at least the given width.
SHORter
Finds patterns shorter than the given width.
Waveform analysis
