Remote control commands
R&S
®
RTM3000
507User Manual 1335.9090.02 ─ 09
CALCulate:MATH<m>:HISTory:CONTrol:ENABle] <PlayerControlEnable>
BUS<b>:HISTory:CONTrol:ENABle] <PlayerControlEnable>
DIGital<m>:HISTory:CONTrol:ENABle] <PlayerControlEnable>
LOGic<p>:HISTory:CONTrol:ENABle] <PlayerControlEnable>
CHANnel<m>:HISTory:CONTrol:[ENABle] <PlayerControl>
Displays or hides the history player on the screen.
Parameters:
<PlayerControl> ON | OFF
*RST: OFF
CALCulate:MATH<m>:HISTory:CURRent
<CurrentAcquisition>
BUS<b>:HISTory:CURRent <CurrentAcquisition>
DIGital<m>:HISTory:CURRent <CurrentAcquisition>
LOGic<p>:HISTory:CURRent <CurrentAcquisition>
SPECtrum:HISTory:CURRent <CurrentAcquisition>
CHANnel<m>:HISTory:CURRent <CurrentAcquisition>
Accesses a particular history segment in the memory to display it. The query returns
the index of the segment that is shown.
Parameters:
<CurrentAcquisition> Segment index. There are two ways to enter the index.
Negative index count: the newest segment has the index "0",
older segments have a negative index: -(n-1), .... -1 , 0
Positive index count: the oldest segment has the index 1, and
the newest segment has the index n: 1, 2,..., n
where n is the number of acquired segments.
CALCulate:MATH<m>:HISTory:PALL <PlayAll>
BUS<b>:HISTory:PALL <PlayAll>
DIGital<m>:HISTory:PALL <PlayAll>
LOGic<p>:HISTory:PALL <PlayAll>
SPECtrum:HISTory:PALL <PlayAll>
CHANnel<m>:HISTory:PALL <PlayAll>
Enables the replay of all acquired segments.
Parameters:
<PlayAll> ON | OFF
If set to OFF, define the range of segments to be shown using
CHANnel<m>:HISTory:STARt and CHANnel<m>:HISTory:
STOP
*RST: ON
CALCulate:MATH<m>:HISTory:STARt <StartAcquisition>
BUS<b>:HISTory:STARt <StartAcquisition>
DIGital<m>:HISTory:STARt <StartAcquisition>
