Remote control commands
R&S
®
RTM3000
595User Manual 1335.9090.02 ─ 09
NORMal
Values that occur frequently are brighter than rare values.
INVerse
Rare values are brighter than frequent values, inverse to the
NORMal brightness.
FColor
Rare values are displayed in blue, while more frequent values
are red and very frequent values are displayed in yellow or
white, with various colors inbetween.
IFColor
Inverses the FColor setting: rare values are yellow or white while
frequent values are blue.
*RST:
NORM
DISPlay:STYLe
<Style>
Defines how the waveform data is displayed
Parameters:
<Style> VECTors | DOTS
VECTors
Individual data points are connected by a line.
DOTS
Only the data points are displayed.
*RST: VECT
DISPlay:GRID:ANNotation[:ENABle] <State>
Enables or disables the display of scale values and units for the x-axis and y-axis at
the grid lines.
Parameters:
<State> ON | OFF
*RST: ON
DISPlay:GRID:ANNotation:TRACk <State>
If enabled, the grid moves with the waveforms, if you change the waveform's position
in horizontal or vertical direction.
If disabled, the grid remains centered on the display, if you change the waveform's
position.
Parameters:
<State> ON | OFF
*RST: OFF
General instrument setup
