Example:
TRIG:A:I2C:PLEN 1
TRIG:A:I2C:PATT "110"
TRIG:A:I2C:PATT?
Return value (1 byte): "110XXXXX"
TRIGger:A:I2C:PLENgth <PatternLength>
Defines how many bytes are considered in the trigger condition. To set the pattern for
these bytes, use TRIGger:A:I2C:PATTern.
Parameters:
<PatternLength> Number of bytes
Range: 1 to 3
Increment: 1
*RST: 1
TRIGger:A:I2C:POFFset <PatternByteOffset>
Sets the number of bytes before the first byte of interest, relating to the end of the
address bytes.
Parameters:
<PatternByteOffset> Number of ignored bytes
Range: 0 to 4095
Increment: 1
*RST: 0
17.11.3.3 I²C - decode results
In all BUS<b>:I2C... commands, the suffix <b> selects the bus.
BUS<b>:I2C:FCOunt?....................................................................................................623
BUS<b>:I2C:FRAMe<n>:DATA?......................................................................................623
BUS<b>:I2C:FRAMe<n>:STATus?...................................................................................623
BUS<b>:I2C:FRAMe<n>:STARt?.....................................................................................624
BUS<b>:I2C:FRAMe<n>:STOP?..................................................................................... 624
BUS<b>:I2C:FRAMe<n>:AACCess?................................................................................624
BUS<b>:I2C:FRAMe<n>:ACCess?..................................................................................624
BUS<b>:I2C:FRAMe<n>:ACOMplete?............................................................................. 625
BUS<b>:I2C:FRAMe<n>:ADBStart?................................................................................ 625
BUS<b>:I2C:FRAMe<n>:ADDRess?................................................................................625
BUS<b>:I2C:FRAMe<n>:ADEVice?.................................................................................626
BUS<b>:I2C:FRAMe<n>:AMODe?.................................................................................. 626
BUS<b>:I2C:FRAMe<n>:ASTart?.................................................................................... 626
BUS<b>:I2C:FRAMe<n>:BCOunt?.................................................................................. 627
BUS<b>:I2C:FRAMe<n>:BYTE<o>:ACCess?................................................................... 627
BUS<b>:I2C:FRAMe<n>:BYTE<o>:ACKStart?................................................................. 627
