Remote control commands
R&S
®
RTM3000
636User Manual 1335.9090.02 ─ 09
<n> *
Selects the frame.
Return values:
<TxFrameState> STER | SPER | PRER | BRE | OK | INS
STER: start error, no start bit found.
SPERr: stop error, no stop condition found.
PRER: parity error, which indicates a transmission error.
BRE: break condition found. A start bit is not followed by a stop
bit, and the data line remains at logic 0 for longer than a UART
word.
OK: the frame is valid.
INS: the frame is not completely contained in the acquisition.
The acquired part of the frame is valid.
Usage: Query only
BUS<b>:UART:FRAMe<n>:WCOunt?
BUS<b>:UART:RX:FRAMe<n>:WCOunt?
BUS<b>:UART:TX:FRAMe<n>:WCOunt?
Returns the number of symbols in the specified frame.
Suffix:
<b>
.
1..4
<n> *
Selects the frame.
Return values:
<WordCount> Number of words (symbols, characters)
Usage: Query only
BUS<b>:UART:FRAMe<n>:WORD<o>:SOURce?
Returns the line on which the specified word was transferred.
Suffix:
<b>
.
1..4
<n> *
Selects the frame.
<o> *
Selects the word.
Return values:
<Source> TX or RX
Usage: Query only
Serial bus analysis
