Remote control commands
R&S
®
RTM3000
688User Manual 1335.9090.02 ─ 09
Parameters:
<StatusBit> 0 | 1 | X
*RST: X
TRIGger:A:MILStd:SYNC <SyncMode>
Triggers on a sync impulse. You can select to trigger on comando/status, on data or on
either syncs.
Parameters:
<SyncMode> CSTatus | DATA | EITHer
*RST: CST
TRIGger:A:MILStd:TRMode
<DataDirection>
Triggers on a transmission mode.
Parameters:
<DataDirection> TRANsmit | RECeive | EITHer
*RST: EITH
TRIGger:A:MILStd:TTYPe <TransmissionType>
Sets the transmission type to be triggered on.
Parameters:
<TransmissionType> BCRT | RTBC | RTRT | MCData
BCRT: bus controller to remote terminal transmission.
RTBC: remote terminal to bus controller transmission.
RTRT: remote terminal to remote terminal transmission.
MCData: mode code data.
*RST: BCRT
TRIGger:A:MILStd:TYPE <TriggerMode>
Selects the type of trigger.
Parameters:
<TriggerMode> SYNChronization | FRAME | ERRor | COMMand | STATus |
DATA
*RST: SYNC
TRIGger:A:MILStd:WCOunt:CONDition <Compare>
Parameters:
<Compare> EQUal | NEQual | GTHan | GEQual | LEQual | LTHan | WITHin |
OUTSide
*RST: OFF
Serial bus analysis
