Operation
R-Concept
143 / 564
Please fold down bunker bar Raise bunker auger front
Lower bunker auger rear Raise bunker auger front and rear
Lower bunker auger front Lower bunker auger front and rear
Differential lock engaged Elevator not raised
Operating temperature not
reached
Please switch analogue-rocker to
neutral position
Maintenance position active
Hints on operation
Bunker auger feed direction to the
rear manually
Ready to save
Bunker auger feed direction to the
front manually
Standard coupling mode active
Three-point suspension active left
only
Three-point suspension active
right only
Coupling mode chain hoist right
and left active
Chain hoist active left only
Chain hoist active right only
Manual steering rear axle steering
activated
Please synchronize articulation
steering
Autopilot activated Manual steering articulation acti-
vated
