Operation
Lifter
258 / 564
The distance of the first lifting roller to the lifting share can be adjusted slightly very
quickly by turning the two adjusting spindles shorter (reduce distance to lifting share)
or longer (increase distance to lifting share). After this adjustment the distance of the
sieve conveyor deflector to the last lifting roller must be checked and adjusted if nec-
essary, because it is not adjusted with the previous adjustment.
