Operation
Bunker unloading
330 / 564
(55) Display
(A) Display of current bunker unloading speed
In this display area you can see the current bunker unloading speed in % (vertical light
bars are synchronous with the % indication). The more light bars are displayed, the
higher the current bunker unloading speed is (see the description of rotary wheel (45)).
(B) Display of the set speed for unloading stage 2 cross conveyor
In this display area, you can see the speed in % set in the menu "Main settings", sub-
menu "Bunker", line "Unloading stage 2 speed %" (See Page 333).
(C) Display of bunker unloading active stage
(See Page 331)
(D) Position indication of rear axle steering
