Maintenance and Service
Diesel engine
366 / 564
The main element may, as described below, be cleaned. As slight damage is often
very difficult to detect or cannot be detected at all, we recommend, in order to pro-
tect the engine, always use new filter cartridges. We do not assume any warranty for
cleaned elements and the consequences caused by them.
Never wash or brush out the main element. When blowing out, make sure that no dust
reaches the internal side of the main element. Always blow out from the clean air side
to the inlet side.
Blow out using a compressed air gun.
Then check the cartridge for damage to the paper bellows and the rubber seals. In
case of damage (cracks, buckling, impressions etc.), use a new cartridge.
– Pull the rubber fasteners (2) with max.
15 Nm from the service cover (3).
– Remove the service cover.
– Hold the main filter element by the
handle (4).
– To release the filter, press and tilt the
filter from the seal at any angle of
approximately 5°.
– Remove the filter.
