Service
Guided Maintenance
14 Overload Code Receiver CR – Check if these errors oc-
cur repeatedly or only
sporadically. If the errors
occur repeatedly,
an additional CR8N board
can be used for HiPath
3750 and HiPath 3700.
An upgrade to the next
highest system may be
necessary for all other
systems.
15 Overload Code Sender CS –
Error Class B-23 - Network
60 System hold no buffer available Hard restart Notify appropriate service
support
Error Class B-26 - Presence
0 Unknown card type – Replace board
1 Board out of order Reload board –
2 Maximum number of peripheral boards
exceeded
– Reduce peripheral boards
to maximum number
3 Board type not compatible, slot is already
pre-assigned with a different board model
– Replace board
4 Board is activated – –
Error Class B-28 - Recovery
0 COSMOS error: Data transmission not
possible
Hard restart Notify appropriate service
support
Error Class B-29 - IOP
0 COSMOS error Hard restart Notify appropriate service
support
20 Port table queue is empty Hard restart
24 Board malfunction Reload board –
25 Board reset was detected Reload board –
Table 12-7 HiPath 3000 Class B Error Messages
No. Meaning Action
Recovery
Action
Technician
