Siemens Hipath 5000 Service Manual

Workpoint Clients
P31003-H3560-S403-54-7620, 09/05
10-20 HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
wclient.fm
optiPoint 500
An external power supply unit is always required to operate the optiPoint application module.
The power supply units for optiPoint 410 and optiPoint 420 described in Section 10.7.1.2 are
used. If you already have this type of power supply unit, the second output can be used to pow-
er the optiPoint application module.
10.2.2.4 Possible add-on device configurations
The following table shows the possible configurations for add-on devices on telephones from
the optiPoint 500 family (not optiPoint 500 entry and optiPoint 500 economy).
Table 10-1 Add-on device configurations on an optiPoint 500 telephone
optiPoint 500 telephone 1st add-on device 2nd add-on device
optiPoint 500 basic
optiPoint 500 standard,
optiPoint 500 standard SL
(For U.S. Only)
optiPoint 500 advance
optiPoint key module –
optiPoint key module optiPoint key module
optiPoint key module optiPoint BLF
optiPoint application module –
optiPoint application module optiPoint key module
optiPoint application module optiPoint BLF
optiPoint BLF –
optiPoint BLF optiPoint BLF
1
1 Configuration with two optiPoint BLFs only with HiPath 3800, HiPath 3750, and HiPath 3700
