Siemens Hipath 5000 - Figure 3-100 S Bus - Example of Jack Assignment (Not for U.S.)

Boards for HiPath 3000
P31003-H3560-S403-54-7620, 09/05
3-240 HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
boards.fm
Peripheral Boards
S
0
bus - example of jack assignment (not for U.S.)
Figure 3-100 S
0
Bus - Example of Jack Assignment (Not for U.S.)
>
ISDN boards can also be connected to available optiPoint 500 series telephones (ex-
cept for optiPoint 500 entry and optiPoint 500 economy) using an optiPoint ISDN
Adapter.
UAE
connector
230 Vac
1. Mini-Western
jack (MW8 = 8-pin):
SR.1 Receive 6
SX.1 Transmit 4
SX.2 Transmit 5
SR.2 Receive 3
2nd to 8th Mini-
Western jack
(MW8 = 8-pin)
Terminating resistors in the last
jack: 2 x 100 ohms,
V39230-Z4101-F
from MDFU/
patch panel
7
SR
6 58 4 3 2 1
SX SX SR
7 6 58 4 3 2 1
6
5
4
3
S
0
power
supply
unit
(Sedlbauer AG)
