Installing HiPath 3000
P31003-H3560-S403-54-7620, 09/05
4-38 HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
inst_h3.fm
Installing HiPath 3800
Figure 4-20 HiPath 3800 - Slots for LUNA2 and REALS in the Basic Cabinet (With Out-
er Panel Mounted)
Figure 4-21 HiPath 3800 - Slots for LUNA2 in the Expansion Cabinet (With Outer Panel
Mounted)
Fixing screws
Fixing screws
