Boards for HiPath 3000
P31003-H3560-S403-54-7620, 09/05
3-304 HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
boards.fm
Peripheral Boards
Front panel
Figure 3-122 TMEW2 - Front Panel (S30810-Q2292-X100)
>
To ensure sufficient shielding, provide the board with a shielding panel. For informa-
tion on mounting the shielding panel, see Section 4.2.5.2.
Two LEDs indicating the board status:
● LED (red)
● LED (green)
