Siemens Hipath 5000 - Figure 3-58 IVMNLIVMN8 - Front Panel (S30122-H7688-X -X100)

Boards for HiPath 3000
P31003-H3560-S403-54-7620, 09/05
3-122 HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
boards.fm
Peripheral Boards
Front panel
Figure 3-58 IVMNL/IVMN8 - Front Panel (S30122-H7688-X -X100)
Lockout switch
Two LEDs indicating the board status:
● LED (green)
● LED (yellow)
Ethernet (10/100BaseT) interface (8-pin RJ45 jack)
