Identifying System Power Requirements
P31003-H3560-S403-54-7620, 09/05
D-6 HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
power_calc.fm
HiPath 3550 Board Power Requirement
D.3 HiPath 3550 Board Power Requirement
Table D-5 Nominal Output of the HiPath 3550 Power Supply Units
Power Supply Unit Part Number Max. Nominal Output in W
5V –48V
UPSC-D S30122-K5660-M300 40.0 53.0
UPSC-D with EPSU2 S30122-K5660-M300 with
S30122-K7221-X2
40.0 140.0
>
You must check whether the total power requirement of the boards used and the
connected workpoint clients exceeds the maximum possible output of the UPSC-D
with or without EPSU2. Section D.8 contains a sample calculation.
Table D-6 HiPath 3550 Board Power Requirement
Board or Component Part Number Net Power Requirement in
W
5V –48V
BS3/1 S30807-H5482-X – 2.0
BS3/3 S30807-H5485-X – 3.0
CBCC (including submod-
ules)
S30810-Q2935-A301 7.0 0.5
GEE12 S30817-Q951-Axxx 0.5 –
GEE16 S30817-Q951-Axxx 0.5 –
GEE50 S30817-Q951-Axxx 0.5 –
HXGS3 (including ventilator
kit)
S30810-Q2943-X 10.0 2.8
HXGS3 (excluding ventilator
kit)
S30810-Q2943-X 10.0 –
IVMS8 S30122-Q7379-X 2.6 0.3
PDM1 S30807-Q5692-X100 – 5.0
SLA8N S30810-Q2929-X200 0.2 0.5
SLA16N S30810-Q2929-X100 3.0 3.0
SLA24N S30810-Q2929-X 4.5 4.5
SLC16N S30810-Q2193-X100 5.0 –
SLMO24 S30810-Q2901-X 1.5 –
