Siemens Hipath 5000 Service Manual

Installing HiPath 3000
P31003-H3560-S403-54-7620, 09/05
4-186 HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
inst_h3.fm
Installing HiPath 3550, HiPath 3350, HiPath 3500, and HiPath 3300
Static traffic capacity
The HiPath 3550 and HiPath 3350 systems have the following static traffic capacities.
Table 4-21 HiPath 3550 and HiPath 3350 - Static Traffic Capacity
System Slots Static traffic capac-
ity
Total static traffic capacity
of the system
HiPath 3550
(see Figure 4-
104)
2 / 3 (CBCC) 24 erlangs
198 erlangs
4 16 erlangs
5 16 erlangs
6 16 erlangs
7 16 erlangs
8 16 erlangs
9 30 erlangs
1
1 Use of a TS2 board results in a capacity of 30 erlangs. A maximum of one TS2 per HiPath 3550 is possible, and the board
may only be installed in slot 7 or 9, thus resulting in 30 Erlangs for slot 7 or 9.
10 64 erlangs
HiPath 3350
(see Figure 4-
107)
2 / 3 (CBCC) 24 erlangs
56 erlangs4 16 erlangs
5 16 erlangs
