Boards for HiPath 3000
P31003-H3560-S403-54-7620, 09/05
3-300 HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
boards.fm
Peripheral Boards
3.3.34 TMDID8 (for U.S. only)
Introduction
TMDID8 (Trunk Module Direct Inward Dialing) provides direct inward dialing from the central
office (CO) to HiPath 3750 and HiPath 3700.
The board has eight trunk circuits that connect to analog trunks.
The circuits can be set up for immediate start or wink start.
Switches and LEDs
Figure 3-121 TMDID8 (for U.S. only) (S30810-Q2507-X)
T4 T3 T2 T1
H1 H2 H3 H4 H5 H6 H7 H8
T8 T7 T6 T5
S4 S3
Trunk 7
Trunk 8
Tru nk 5
Tru nk 6
S2 S1
Tru nk 3
Tru nk 4
Trunk 1
Trunk 2
A
G
A
G
A
G
A
G
