Boards for HiPath 3000
P31003-H3560-S403-54-7620, 09/05
3-374 HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
boards.fm
Options
Figure 3-166 REALS (S30807-Q6629-X)
To the SIPAC 4SU connector X17
Signals are picked up via SIVAPAC connec-
tor X116 on the backplane.
Removal tab
You can insert a screwdriver here to remove REALS from the shelf.
