HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
4-95
Installing HiPath 3000
Installing HiPath 3750, HiPath 3700
4.3.3.4.3 Setting Up a Single Cabinet
Procedure
4.3.3.4.4 Mounting a One-Cabinet System on the Wall (for U.S. only)
You can mount a one-cabinet system on the wall using the wall-mount kit.
Wall-Mount Kit
Procedure
Step Activity
1. Remove the front and rear cover from the cabinet.
2. Place the system cabinet in the installation site and make sure that it is level and
stable.
Figure 4-50 HiPath 3750 - Wall-Mount Kit (for U.S. only)
Step Activity
1. Install a plywood backboard at least 0.75 in. (19.05 mm) thick.
Latching assembly Bracket for wall mounting
Latch
Keyed holes
Swing-out component
