boards.fm
P31003-H3560-S403-54-7620, 09/05
HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
3-377
Boards for HiPath 3000
Options
14
blk/brn 30 RK1 14a
Relay 1: Normally
closed contact
brn/blk 29 RK2 14b
Relay 2: Normally
closed contact
15
blk/gry 27 RK4 15a
Relay 4: Normally
closed contact
gry/blk 26 0 V 15b
16
yel/blu 24 PFTTSb 16a
ALUM: Subscriber line
module
blu/yel 23 PFTTSa 16b
17
yel/ora 58 – 17a
ora/yel 57 S5 17b
18
yel/grn 56 0 V 18a
grn/yel 55 – 18b
19
yel/brn 54 – 19a
brn/yel 53 S3 19b
20
yel/gry 52 S4 20a
gry/yel 51 0 V 20b
21
vio/blu 50 UK1 21a Relay 1: Switch contact
blu/vio 49 UK2 21b Relay 2: Switch contact
22
vio/ora 48 UK3 22a Relay 3: Switch contact
ora/vio 47 UK4 22b Relay 4: Switch contact
23
vio/grn 46 0 V 23a
grn/vio 45 – 23b
24
vio/brn 44 – 24a
brn/vio 43 S6 24b
Table 3-174 REALS - SIVAPAC Connector Assignment on the Backplane
Pair
a-Wire
(Tip)
b-Wire
(Ring)
SIVAPAC Connec-
tor X116
REALS MDFU-E Notes
