12.3.1.6.3 The Screen Layout of the Trace Monitor
When you start the Trace Monitor, an application window with the following layout appears:
Figure 12-2 The Screen Layout of the Trace Monitor
Trace window sys-
tem menu
Title bar
Menu bar
Workspace
(open trace win-
dows)
Trace Monitor sys-
tem menu
Minimize
Maximize
Exit
Status bar
