Boards for HiPath 3000
Peripheral Boards
3.3.29 TM2LP
Introduction
The TM2LP (Trunk Module Loop Procedure) board connects up to eight analog trunks to Hi-
Path 3800 using the loop-start protocol.
Front panel
Figure 3-113 TM2LP - Front Panel (S30810-Q2159-Xxxx)
>
To ensure sufficient shielding, provide the board with a shielding panel. For informa-
tion on mounting the shielding panel, see Section 4.2.5.2.
Two LEDs indicating the board status:
● LED (red)
● LED (green)
