Siemens Hipath 5000 - Table 3-167 ANI4 (for Selected Countries Only) - Contact Assignments

Boards for HiPath 3000
P31003-H3560-S403-54-7620, 09/05
3-348 HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
boards.fm
Options
ANI4 module contact assignments
Table 3-167 ANI4 (for selected countries only) - Contact Assignments
Contact Connector X3
Component Side
Connector X3
Solder Side
Connector X4
1 -- Not assigned a-wire (tip), trunk 1
2 b-wire (ring), trunk 1 -- b-wire (ring), trunk 1
3 -- a-wire (tip), trunk 1 a-wire (tip), trunk 2
4 b-wire (ring), trunk 2 -- b-wire (ring), trunk 2
5 -- a-wire (tip), trunk 2 a-wire (tip), trunk 3
6 b-wire (ring), trunk 3 -- b-wire (ring), trunk 3
7 -- a-wire (tip), trunk 3 a-wire (tip), trunk 4
8 b-wire (ring), trunk 4 -- b-wire (ring), trunk 4
9 -- a-wire (tip), trunk 4 –
10 GMZ -- –
GMZ= Call charging module assignment
