HiPath Cordless Office
System Configuration
11.3 System Configuration
The following table indicates the maximum possible system configuration parameters for Hi-
Path Cordless Office. It also shows when
● CMA or CMS is necessary
● analog trunk access is possible.
Table 11-1 HiPath Cordless Office - System Configuration for HiPath 3000 V6.0
System
Max.
no.
Clock modules
Maximum number of base sta-
tions BS with connection via
1xU
P0/E
Simultaneous
calls per BS
Max. no.
MTs
Analog
trunk access
to system
SLC16N
SLCN
BS3/1
BS3/S
BS2/2
BS3/3
BS4
BS3/1
BS3/S
BS2/2
BS3/3
BS4
HiPath 3350
HiPath 3300
––CMS–1––––2––– 8 No
––CMA–1––––4––– 8 Yes
––CMA3–––34–––4 16 Yes
HiPath 3550
HiPath 3500
––CMS–1––––2––– 8 No
––CMA–1––––4––– 8 Yes
––CMA7–––74–––4 32 Yes
HiPath 3550 1 – CMS 16 – 8 8 16 4 – 8 12 12 64 Yes
HiPath 3750
HiPath 3700
4 – CMS 64 – 32 32 64 4 – 8 12 12
250 (with 4
SLC16N)
1
1 Up to 128 handsets are possible at an SLC16N.
Yes
HiPath 3800 – 4 CMS 64 – 32 32 64 4 – 8 12 12
250 (with 4
SLCN)
2
2 Up to 128 MTs are possible at an SLCN.
Yes
Explanations:
● BS2/2 (S30807-H5471-X200) is a base station that supports a maximum of 8 calls when connected using
two U
P0/E
interfaces.
● BS3/1 (S30807-H5482-X): is a base station that supports a maximum of 4 calls.
● BS3/3 (S30807-H5485-X): is a base station that supports a maximum of 12 calls when connected using
three U
P0/E
interfaces.
● BS3/S (X30807-X5482-X100): The BS3/S single-cell base station guarantees the operation of a maximum
of one base station on the U
P0/E
interfaces of the central board. It is not possible to operate additional base
stations.
● BS4 (S30807-U5491-X): is a base station that supports a maximum of 12 calls when connected using three
U
P0/E
interfaces. In the case of a direct connection, it is only permitted to make the connection via one U
P0/
E
interface. The B channels in the base station BS4 require a license (see Chapter 8).
