Siemens Hipath 5000 - Table 3-119 TLA4 R (Not for U.S.) Contact Assignments

Boards for HiPath 3000
P31003-H3560-S403-54-7620, 09/05
3-268 HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
boards.fm
Peripheral Boards
3 34 a trunk 3
35 b trunk 3
4 44 a trunk 4
45 b trunk 4
MW8 Jack X5, pin ALUM 1 + 2
5 54 TB1 ALUM1: Stn card connection
55 TA1
6 64 TB2 ALUM2: Stn card connection
65 TA2
7 74 BE1 ALUM1: Analog telephone
connection
75 AE1
8 84 BE2 ALUM2: Analog telephone
connection
85 AE2
Table 3-119 TLA4R (Not for U.S.) Contact Assignments
