Siemens Hipath 5000 Service Manual

wclient.fm
P31003-H3560-S403-54-7620, 09/05
HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
10-1
Workpoint Clients
Overview
10 Workpoint Clients
10.1 Overview
Chapter contents
This chapter discusses the topics listed in the following table.
Topic
optiPoint 500, page 10-4
● optiPoint 500 Telephones, page 10-6
– optiPoint 500 entry
– optiPoint 500 economy (not for U.S.)
– optiPoint 500 basic
– optiPoint 500 standard, optiPoint 500 standard SL (For U.S. Only)
– optiPoint 500 advance
– Connection Requirements for HiPath 3000
– Connection
– Connections on the Bottom of the Telephone
– USB 1.1 Interface
● optiPoint 500 Add-On Devices, page 10-17
– optiPoint key module
– optiPoint BLF
– optiPoint application module (V5.0 SMR-06 and later)
– Possible add-on device configurations
● optiPoint 500 Adapters, page 10-21
– optiPoint Analog Adapter
– optiPoint ISDN Adapter
– optiPoint Phone Adapter
– optiPoint Acoustic Adapter
– optiPoint Recorder Adapter
– Possible optiPoint Adapter Configurations
– Comparison of optiset E adapters and optiPoint 500 adapters
● Information on supplying power to optiPoint 500 add-on devices and optiPoint 500 adapt-
ers, page 10-32
● Maximum Configuration for UP0/E Workpoint Clients, Add-On Devices and Adapters,
page 10-33
optiPoint 410 / optipoint 410 S and optiPoint 420 / optiPoint 420 S, page 10-36
● IP Telephony (Voice over IP), page 10-38
