Installing HiPath 3000
P31003-H3560-S403-54-7620, 09/05
4-24 HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
inst_h3.fm
Installing HiPath 3800
4.2.4.1.1 For U.S. only: AC outlet
An AC connection is required for each cabinet. The AC connection must fulfill the requirements
specified in Table 4-3.
The system must be properly grounded before startup (see description in Section 4.2.4.4).
4.2.4.2 Unpacking the Components
Procedure
Table 4-3 Electrical Connection Values (USA only)
Nominal
voltage
Nominal voltage range Nominal Frequency
Range
Wall Outlet Configura-
tions
from to from to
120 V AC/
60 Hz
110 V AC 130 V AC 47 Hz 63 Hz NEMA 5-15, 2-pin, 3-
wire, earth
Step Activity
1. Compare the components with the packing slip or customer receipt to make sure
that they are correct and complete.
2. Determine whether any damage has occurred during transport and report it to the
proper departments.
3. Dispose of the packing materials properly.
7
Caution
Only use tools and equipment that are in perfect condition. Do not use equipment
with visible damage.
