boards.fm
P31003-H3560-S403-54-7620, 09/05
HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
3-165
Boards for HiPath 3000
Peripheral Boards
Figure 3-75 EPSU2 - Indicators and Ports
Housing cover
AC port for 100 – 240 Vac
DC port for UPSC-D
Note polarity.
Mounting
screws
LED 1
LED 2
Battery fuse
