3.2.15 MMC
Introduction
The Multi Media Card (MMC) is a plug-in memory card for the central control boards and con-
tains the CDB backup and the relevant version-specific application processor software (APS).
Please note that the MMC may only be replaced by a multimedia card approved by Siemens
AG. Cards that have not been approved may have a different internal structure which can affect
temporal access and certain features (for example, CDB backup and APS transfer).
>
HiPath 3000 V5.0 (or later) only supports 64 MB multimedia cards (MMC64).
MMC16 (16 MB) cards cannot be used.
The MMC is checked during system startup. If the system detects an MMC16, the
startup is aborted.
Table 3-27 Multimedia Card Models and Applications
MMC Part number Applica-
tion
in
countries
Application in HiPath 3000
HiPath 3800
HiPath 3750
HiPath 3550
HiPath 3350
HiPath 3350
with CBCC
HiPath 3700
HiPath 3500
HiPath 3300
HiPath 3300
with CBRC
HiPath 3000 Version 4.0
MMC16
(16 MB)
S30122-X7424-X
(= empty basic MMC)
ROW X X X X X X X X
P50038-P1009-A816 X X
P50038-P1010-A816 X X X X
P50038-P1011-A816 X X
MMC64
(64 MB)
S30122-X8002-X10
(= empty basic MMC)
ROW X X X X X X X X
P50038-P1010-A864 X X X X X X
P50038-P1011-A864 X X
HiPath 3000 Version 5.0
MMC64
(64 MB)
S30122-X8002-X10
(= empty basic MMC)
ROW X X X X X X X X X
P50038-P1053-A816 X
P50038-P1054-A816 X X X X X X X X
