Siemens Hipath 5000 Service Manual

inst_h3.fm
P31003-H3560-S403-54-7620, 09/05
HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
4-133
Installing HiPath 3000
Installing HiPath 3750, HiPath 3700
4.3.4.3.2 Mounting the System Cabinet with Angle Brackets
An assembly kit (C39165-A7027-D5) with eight angle brackets is provided for installing the 19-
inch cabinet.
Procedure
7
Warning
Never attempt to lift a system cabinet into the 19-inch cabinet without assistance.
Step Activity
1. Attach a right-handed and a left-handed support bracket (A in Figure 4-74) to the
19-inch cabinet using two screws per bracket.
2. Remove the front and rear cabinet covers.
3. Remove both side pieces of the system cabinet.
4. Attach the two angle brackets (B in Figure 4-74) to the front of the system cabinet
using two screws per bracket.
5. Attach the four angle brackets (C in Figure 4-74) to the rear of the system cabinet
for base and cover support.
6. Lift the system cabinet into the 19-inch cabinet and sit the cabinet on the two sup-
port brackets (A). Slide the cabinet into the 19-inch cabinet until the front edge of
the system cabinet is flush with the front of the 19-inch frame.
7. Attach the system cabinet to the angle bracket (B) in the 19-inch cabinet frame
using two screws per bracket.
