Expanding and Upgrading HiPath 3000
P31003-H3560-S403-54-7620, 09/05
9-28 HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
exup.fm
Expanding HiPath 3000
Connecting speakers to an analog trunk port
Figure 9-14 Connecting Speakers to an Analog Trunk Port
HiPath 3000
TML/TLA
HiPath 3000
TML/TLA
Amplifier
T/R
Active speakers
only
T/R
REAL/STRB
Starting contact
