Starting HiPath 3800 as a Gateway
7.3 Starting HiPath 3800 as a Gateway
7.3.1 Prerequisites
Refer to Section 4.2.1 for information on the tools and resources needed to install the HiPath
3800 system.
7.3.2 Procedure for Installation and Startup
7
Warning
Only authorized service personnel should install and start up the system.
>
To ensure that IP addresses are not assigned more than once in the customer net-
work, you must ping each new IP address to be configured before each IP address
is assigned. If an IP address responds, then this address cannot be used again.
Table 7-1 HiPath 3800 as a Gateway - Procedure for System Installation and Startup
Step Activity (Remarks)
Installing HiPath 3800 (19-Inch Cabinet)
1. Selecting the Installation Site, page 4-21 (generally determined by the existing 19-
inch cabinet)
2. Unpacking the Components, page 4-24
3. Mounting System Cabinets in the 19-Inch Cabinet, page 4-25
4. Grounding the System, page 4-28
Checking the Grounding, page 4-30
5. Connecting the Cable to the Backplane, page 4-51
6. If required: Inserting the External Patch Panel, Page 4-66
7. Loading the System Software and Installing Subboards on the CBSAP, page 4-81
8. Installing Boards (Configuration Notes), page 4-31 (cabinet(s) are already
equipped with the boards)
We recommend that you check the board population using the configuration notes.
9. Making trunk connections
Refer to the following board descriptions for information:
● STMD3 - for S
0
trunk connection
● DIUN2 - for S
2M
trunk connection
● DIU2U (For U.S. Only) - for T1 PRI trunk
