Installing HiPath 3000
Installing HiPath 3750, HiPath 3700
4.3.3.4 Setting up the System Cabinets
Introduction
Cabinets are supplied fitted with the specific boards required by the customer.
4.3.3.4.1 Overview
System configurations
The following setup options are possible for system cabinets:
7
Warning
A fully equipped HiPath 3750 cabinet weighs 22 kg (48.46 lb). We recommend lifting
cabinets only before they are equipped. Do not attempt to lift objects that you think
are too heavy for you; use a hand truck or get assistance.
7
Danger
Be sure to ground the system properly before starting it up and connecting the sta-
tions.
System
One cabinet on a horizontal surface
One cabinet on a wall (for U.S. only)
Two cabinets stacked on a horizontal surface
Two cabinets stacked on a wall (for U.S. only)
Two cabinets side-by-side on a horizontal surface
Three cabinets on a horizontal surface (two stacked)
