Siemens Hipath 5000 - CUP and CUPR

boards.fm
P31003-H3560-S403-54-7620, 09/05
HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
3-47
Boards for HiPath 3000
Central Boards
3.2.9 CUP and CUPR
The backplane comes in two versions:
● CUP (Connection Unit Point) S30777-Q751-X (Figure 3-11) - for use in HiPath 3350 (wall
housing)
● CUPR (Connection Unit Point Rack) S30777-Q751-Z (Figure 3-12) - for use in HiPath 3300
(19-inch housing)
CUP connector designations and slot assignments (S30777-Q751-X)
CUPR connector designations and slot assignments (S30777-Q751-Z)
Figure 3-11 CUP Backplane (S30777-Q751-X)
Figure 3-12 CUPR Backplane (S30777-Q751-Z)
Slot 4 (X20) Slot 5 (X30)PSU/UPS (X1)
CUP
Slot 2 (8 x U
P0/E
) Slot 1 (2 x S
0
) Slot 3 (4 x T/R)
Peripheral board
CBCC
Slot 4 (X20) Slot 5 (X30)PSU/UPS (X1)
CUPR
Slot 2 (8 x U
P0/E
) Slot 1 (2 x S
0
) Slot 3 (4 x T/R)
Peripheral board
CBRC
